Printing facilities for Semiconductor device fabrication
Complete set of processing equipment including evaporators, sputtering, PECVD, RIE and DRIE for inorganic material processing
○ Unique TFT fabrication facility.
○ Unique OLED fabrication facility.
Stand alone slot-die, gravure, flexo, rotary screen, inkjet and bioprinter. Also multi-station roll- to- roll coaterswith interchangeable printing heads in a clean room.
Lithography (including nano and imprint), roll to roll sputter, evaporation, CVD, ALD, laser ablation, OLED cluster tool, PV cell fabrication tools in glove box, laser patterning in a clean room.
Fully functional chemical synthesis facility with chemical characterization tools and ink development facility equipped with tools such as viscometer, rheometer and contact angle measurement system.
Equipped with workstations and most commonly used design tools, such as Inventor, Solidedge, Solidworks and TCAD tools.
CV, parameter analyzer, solar simulator, IPCE, probe station, test station (various electrical sources and meters), reliability tester, electronics component laboratory and oscilloscopes.
GPC, MALDI-TOF mass spectrometer, UV-VIS-NIR spectrophotometer, FTIR, liquid chromatography, dynamic light scattering, TGA. PL, TRPL, AFM, ellipsometer, kelvin probe, FESEM, cyclic voltammetry, electrochemical impedance spectroscopy.
